Water Cooled Marine Diesel Generator , Soundproof Cummins Engine Generator

    Buy cheap Water Cooled Marine Diesel Generator , Soundproof Cummins Engine Generator from wholesalers

    Buy cheap Water Cooled Marine Diesel Generator , Soundproof Cummins Engine Generator from wholesalers
    • Buy cheap Water Cooled Marine Diesel Generator , Soundproof Cummins Engine Generator from wholesalers
    • Buy cheap Water Cooled Marine Diesel Generator , Soundproof Cummins Engine Generator from wholesalers

    Water Cooled Marine Diesel Generator , Soundproof Cummins Engine Generator

    Ask Lasest Price
    Brand Name : GSKA
    Model Number : JP-C1000
    Price : Negotiable
    Payment Terms : T/T L/C, 30% deposit,70% before delivery
    Supply Ability : 100 units/ Per month
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    Water Cooled Marine Diesel Generator , Soundproof Cummins Engine Generator

    Soundproof Water Cooled Marine Diesel Generator Price With Cummins Engine Generator Company


    Engine Data:


    Manufacturer / Model:

    CCEC Cummins KTA38-G9, 4-cycle

    Air Intake System:

    Turbo, Water/Air cooling

    Fuel System:

    PT type fuel pump, EFC

    Cylinder Arrangement:

    12 in “v”

    Displacement:

    37.8L

    Bore and Stroke:

    159*159(mm)

    Compression Ratio:

    13.9:1

    Rated RPM:

    1500rpm

    Max. Standby Power at Rated RPM:

    1089KW/1481HP

    Governor Type:

    Electronic

    Exhaust System

    Exhaust Gas Flow:

    3539L/s

    Exhaust Temperature:

    529 ℃

    Max Back Pressure:

    10kPa

    Air Intake System

    Max Intake Restriction:

    6.23kPa

    Consumption:

    1309L/s

    Air Flow:

    30425L/s

    Fuel System

    100%( Prime Power) Load:

    199 g/Kw.h

    75%(Prime Power) Load:

    204g/Kw.h

    50%(Prime Power) Load::

    213g/Kw.h

    100%( Prime Power) Load:

    200L/h

    Oil System

    Total Oil Capacity

    135L

    Oil Consumption:

    ≤4g/kwh

    Engine Oil Tank Capacity:

    114L

    Oil Pressure at Rated RPM:

    310-448kPa

    Cooling System

    Total Coolant Capacity:

    280L

    Thermostat:

    82-93℃

    Max Water Temperature:

    104℃


    FAQ:
    Q1: Are you trading company or manufacturer ?
    A1: We are factory.
    Q2:What is the power ranger of your diesel generator ?
    A2: We can provide power from the 10kva-2500kva.
    Q3:What is your warranty ?
    A3:Our payment terms is 1 year or 1000 running hours whichever comes first. But based on some special project, we can extended our warranty period.
    Q4:What is your MOQ? A4: MOQ is 1 set.
    Q5:Do your offer OEM Service? A5:Yes.
    Q6:What is the voltage and frequency of your diesel generator?
    A6:50/60HZ,220/380V,230/400V,240/415V,254/440V,or request voltage.
    Q7:What is your lead time?
    A7:Average 15-20days.
