    Generator Accessories Automatic Transfer Switch ATS Model VSQ3-120A

    Ask Lasest Price
    Brand Name : GSKA
    Model Number : VSQ3-120A
    Price : negotiate
    Payment Terms : L/C, T/T
    Supply Ability : 500 Set / Sets per Month
    Delivery Time : 5-7 working days after received deposit
    • Product Details
    • Company Profile

    Generator Accessories Automatic Transfer Switch ATS Model VSQ3-120A

    Generator Accessories Automatic Transfer Switch ATS Model VSQ3-120A


    product presentation:


    Diesel generator ATS is an "automatic switching system", is to control the switch between the mains and the generator device (cabinet), is normal mains power supply, mains power supply automatically or manually switched to the generator power supply after mains interruption! Generally simple is through the knob switch to select automatic, manual, or remote control unit communiCAT-parts-partsion device.


    functional characteristics:


    ◆ Realize the automatic intelligent control of the generator set, realize the automatic switch between the mains and the generator set, meet the unattended requirements

    ◆ Realize remote monitoring of unit and ATS. Provide standard RS-232/485 communiCAT-parts-partsion interface, open communiCAT-parts-partsion protocol and test software

    ◆ The main control module adopts full-function intelligent controller series of diesel generator set

    ◆ High reliability of main switch, less contact relay, low failure rate

    ATS switch has mechanical/electrical interlocking. When the automatic function fails, the main switch can be manually switched by the handle

    ◆ The operation panel of the control panel monitors the real-time status and operation parameters of the mains, diesel generators and ATS on site. Manual/automatic mode can be selected through the controller menu

    ◆ Idle speed, starting time, unloading stop time, main switch time and power high/low voltage value can be set by the controller, the operator can use the film key to observe, modify, control the parameters, setting operation is simple and convenient

    ◆ Can provide detailed records of unit operation events, and provide basis for future maintenance of equipment


    ITEM NO.
    VSQ3-120A
    Rated current Ie(A)
    32A, 40A, 50A, 63A,100A,125A
    Installation
    Din rail
    Rated insulation voltage Ui (V)
    AC690, 50HZ
    Rated working voltage Ue (V)
    AC400, 50HZ
    Rated impulse withstand voltage (KV )
    8KV
    Poles
    2P 3P 4P
    Weight (KG)
    1.7 2.1 2.6
    Connecting and breaking
    6.0Ie 1.05Ue cosØ=0.50±0.05, 50 times
    Operating performance
    2.0Ie 1.05Ue cosØ=0.80±0.05, 6000 times
    Rated limited short-circuit current Iq
    50KA
    SCPD (FUSES )
    RT16-00-63A
    Control circuit
    Rated supply voltage Us: AC220V, 50HZ.
    Working condition:85% Us~110% Us
    Ancillary circuit
    Two isolated relays, each relay with 2 groups of passive
    switch contact. Contact capacity: AC220 50Hz, Ie=5A
    Switching time
    <30ms
    Action time
    <30ms


    FQA:


    1. who are we?
    We are based in Dongguan, China, start from 2021,sell to Mid East(45.00%),North America(35.00%),South America(20.00%). There are
    total about 11-50 people in our office.

    2. how can we guarantee quality?
    Always a pre-production sample before mass production;
    Always final Inspection before shipment;

    3.what can you from us?
    Generator AVR,Generator Controller,Rectifier Diodes,ATS,Solenoid

    4. why should you buy from us not from other supplier?
    1.10 YEARS MANUFACTURE,DESIGN AND RESEARCH EXPERIENCE. 2. Owned 3 factories for AVR CONTROLLER AND RECITIFIER 3. OEM FACTORY FOR
    FAMOUS GENERATOR COMPANY 4. 8 YEARS PROFESSIONAL SALES TEAM TO PROVIDE BEST SERVICE 5. MOST STRICT QUALITY AND COST CONTROL

    5. what services can we provide?
    Accepted Delivery Terms: FOB,CIF,EXW,Express Delivery;
    Accepted Payment Currency:USD,EUR,HKD,CNY;
    Accepted Payment Type: T/T,L/C,MoneyGram,Credit Card,Western Union,Cash,Escrow;
    Language Spoken:English,Chinese
