    Customizable Uninterruptible Power Supply 2kva-10kva For Home

    Ask Lasest Price
    Brand Name : GSKA
    Model Number : UPS uninterruptible power supply
    Price : negotiation
    Supply Ability : 10000 Set / Sets per Month
    Delivery Time : 7-10working days after received deposit
    • Product Details
    • Company Profile

    Customizable Uninterruptible Power Supply 2kva-10kva For Home

    Customizable Uninterruptible Power Supply 2kva-10kva For Home


    product presentation:


    Uninterruptible power supply is also known as standby power supply, main and standby power supply, in the case of power failure, to provide safe and continuous power supply for the system to ensure the normal operation of the system, uninterruptible power supply can also be used to expand the power reserve, in the case of power failure, special conditions can support dozens of times the load capacity. For example, in some trading centers, there are often a lot of high load and power consumption equipment, such as exchanges, because they contain multiple servers and network equipment, the installation of uninterruptible power supply can support the continuity of power supply, so as to ensure the stability of operation.


    feature:


    1.Zero Transfer


    TimeTrue Double Conversion Online UPS,


    provide most comprehensive protection.


    2.Reliable Design


    Made with strong Glass fiber base (FR4)


    double side PCB, company with large span


    component, greatly improve reliability in harsh environment.


    3.OpenTo Customization

    Base on power controller and open architecture,


    the product is able to be customerized to match


    need of integration of automatic system or


    intelligent supervisory system.


    PHASESingle phase with ground
    CAPACITY2000VA/1600W
    INPUT
    Nominal Voltage110Vac
    Voltage Range

    60-138VAC ±5% at 50% load

    80-138VAC ±5% at 100% load

    Frequency Range40Hz-70Hz(46-54Hz default 50Hz;56-64Hz default 60Hz)
    Power Factor≥0.99@nominal voltage(100% load)
    THDi%≤10%
    OUTPUT
    Output Voltage100/110/120/127 VAC)
    AC Voltage Regulation±2%

    FrequencyRange

    (Synchronized Range)

    47-53 Hz or 57-63 Hz
    Frequency Range(Batt.Mode)50 Hz±0.1 Hz or 60 Hz±0.1 Hz
    Current Crest Ratio3:1
    Harmonic DistortionTHD (Linear Load)≤4%,THD (Non-linear Load)≤7%

    Transfer

    Time

    AC to DCzero

    Inverter

    to Bypass

    4ms (Typical)
    ECO to Battery Mode8ms (Typical),10 ms (max)
    WaveformPure Sinewave
    EFFICIENCY
    Line Mode≥89%@battery full charged≥91%@battery full charged
    ECO Mode≥96%@battery full charged
    Battery Mode≥86%
    BATTERY
    Battery Type12V/7AH
    Numbers6
    Typical Recharge Time5hours recover to 95% capacity for internal battery
    Charging Current

    1-3KVA 1A

    1-3KL 4.5A

    Charging Voltage82.5VDC±1%
    INDICAT-parts-partsORS
    LCD PanelLoad level,Battery level, AC mode,Battery mode,Bypass mode,and Fault indiCAT-parts-partsor
    ALARM
    Battery Modebeeps every 5 seconds
    Low Batterybeeps every 2 seconds
    OverloadBeeps every seconds
    FaultContinuously beeps
    PHYSICAL
    Dimension,D*W*H(mm)425*190*328
    Net Weight(long backup )(kgs)12

    Net weight

    (w/built-in batteries)(kgs)

    23
    ENVIRONMENT
    Humidity20-95%RH@0-40℃(non-condensing)
    Noise LevelLess than 50dBA @ 1 Meter
    MANAGEMENT
    Smart RS-232 or USBSupport
    Optional SNMPPower management from SNMP manager and web browser
    STANDARD
    EMC/SafetyEMC EN62040-2 C2 for CE models

    FQA:


    Q1:Main products range


    A: Our main products range is offline ups 600va-3000va, online hight frequency ups 1kva-80kva,online low frequency ups 2kva-200kva,ups


    battery


    12V 7ah-200ah


    Q2:Are you manufacturer or trading company?


    A:we are UPS manufacturer


    Q3:Can I have a sample for testing?


    A:Yes,you can have a sample for testing


    Q4:How do you control quality?


    A: We strictly implement quality control following IQC, IPQC, FQC, QQC standards


    Q5:how long is your deliver time?


    A:normally 15 days


    Q6:How to pay?


    A:We accpect TT and L/C


    Q7:Warranty


    A: 1 year warranty for UPS. 1 year warranty for battery 7AH-17AH. 2 years warranty for battery 24AH-200AH
